MINE Q9 SOLUTION
Mine Q9 5G 4K Bonding Encoder
Video Encoder
MiNEMedia Q9 5G/4G bonding encoder designed for high-quality live streaming with 5 inch Touch Screen.
With 6 SIM slots, including a built-in 1*5G module and 5*4G modules, dual-band WiFi, and a gigabit network port, it ensures reliable and high-speed network connectivity.
It supports 4K encoding, delivering live streams with resolutions up to 2160p@30fps.
It offers HDMI and SDI dual input, with HDMI supporting up to 4K@30fps and SDI up to 1080P@60fps, allowing for flexible input channel switching.
The Mine Q9 also supports recording on a TF card with a maximum capacity of 2TB.
Internal rechargeable battery provides up to 2-3 hours of continuous streaming.
With 6 SIM slots, including a built-in 1*5G module and 5*4G modules, dual-band WiFi, and a gigabit network port, it ensures reliable and high-speed network connectivity.
It supports 4K encoding, delivering live streams with resolutions up to 2160p@30fps.
It offers HDMI and SDI dual input, with HDMI supporting up to 4K@30fps and SDI up to 1080P@60fps, allowing for flexible input channel switching.
The Mine Q9 also supports recording on a TF card with a maximum capacity of 2TB.
Internal rechargeable battery provides up to 2-3 hours of continuous streaming.
MINE Q9 ADVANTAGES
4K Encoding, Decoding, High-definition Quality
4K Live Stream, Resolution can up to 2160@30fps
4K Live Stream, Resolution can up to 2160@30fps
Mix. Monitor Broadcast Grade Audio Processing
Independent audio and video processing chip, AGC automatic gain algorithm, high definition audio input, support for monitoring and dual-channel mixing output
Independent audio and video processing chip, AGC automatic gain algorithm, high definition audio input, support for monitoring and dual-channel mixing output
HDMI/SDI Dual Input
HDMI input up to 4K@30fps
SDI input up to 1080P@60fps
Dual input channel switch freely
HDMI input up to 4K@30fps
SDI input up to 1080P@60fps
Dual input channel switch freely
Mine Q9 Basic Parameters
| Model | Mine Q9 |
| Name | 5G/4G Bonding Encoder |
| Video | |
| Input | 1* HDMI & 1* SDI |
| Resolution | 480i: 720×480@59.94i 576i: 720×576@50i 1280×720@25p/30p/50p/60p/120p 1080p: 1920×1080@50i/60i 1080p: 1920×1080@25p/30p/50p/60p 2160p: 3840×2160@25p/30p |
| Encoding Levels | H.265 Main profile, H.264/AVC High / Main / Baseline Profile |
| Stream Resolution | 480×270, 640×360, 848×480, 960×540, 1280×720 1920×1080, 3840×2160 |
| Encoding Video FPS | 15-60FPS |
| Encoding Video Bitrate | adjustable |
| Bitrate control | VBR / CBR |
| Recording resolution | Max 2160p30 |
| TS Protocols | RTMP(S) / SRT / RTSP |
| Audio | |
| Input | HDMI & SDI embed Audio and 1* 3.5mm dual-channel external audio |
| Output | 1*3.5mm dual-channel audio monitoring |
| Built-in | Loudspeaker |
| Sample Rates | 44.1kHz, 48.0 kHz |
| Encoding | AAC |
| Network | |
| 6 SIM Slots | Built-in 5G module * 1 & 4G module * 5 |
| WiFi | 2.4G/5.8G dual-band WIFI access |
| RJ45 | Gigabit network port |
| USB | External 4G dongle, USB network card can be used |
| Storage | TF card (Max 2TB) |
| Power | |
| Power supply | DC12 5A |
| Battery Capacity | 7.4V/12000mAh |
| Maximum consumption | 35W |
| System | |
| Control Panel | iOS / Android APP |
| Firmware Update | supports |
| Remote management | supports |
| Working Environment | |
| Operating temperature | -20 to 80 deg C |
| Storage temperature | -40 to 90 deg C |
| Relative Humidity | 5% to 90% non-condensing |
| Dimension & Accessories | |
| Dimension | 223mm*147mm*58mm |
| Weight | 1300g |
WHAT'S IN THE BOX
Package includes:
Q9 5G 4K Bonding Encoder *1
Protective suite case*1
HDMI cable*1
SDI cable*1
Power adapter*1
Manual*1
Backpack*1 (Optional)
Mine Q9 Size
